Efficiently harvest every watt of solar energy with the Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20) from Nomadic Supply Company®. Designed for small to mid-size 12V/24V solar arrays up to 260 watts, the Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20) uses Maximum Power Point Tracking technology to deliver up to 30% more charging efficiency than standard PWM controllers. Compact and easy to install, this controller protects your batteries with multi-stage charging and comprehensive overload safeguards.
Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20) Features:
- 20A MPPT Charging. Handles up to 20 amps of battery charging current with Maximum Power Point Tracking for peak efficiency in varying light conditions.
- Up to 98% Conversion Efficiency. Minimizes energy loss between your panels and batteries, putting more harvested solar power to work.
- 12V/24V Auto-Detection. Automatically identifies your battery bank voltage and configures itself — no manual switching required.
- 100V Max PV Input. Accepts up to 100 volts DC from your solar array, supporting flexible panel configurations up to 260W at 12V or 520W at 24V.
- Multi-Battery Compatibility. Supports Gel, AGM, Flooded, Calcium, and LiFePO4 battery types with programmable charging profiles.
- Comprehensive Protection. Built-in safeguards against overcharge, over-discharge, short circuit, reverse polarity, and overload conditions.
Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20) Includes:
- 1 x Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20)
Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20) Specifications:
- System Voltage: 12V/24V Auto
- Battery Current Rating: 20A
- Load Current Rating: 20A
- Max PV Input Voltage: 100 VDC
- Max Power Input: 260W (12V) / 520W (24V)
- MPPT Tracking Efficiency:>99%
- Conversion Efficiency: ≤98%
- Protection Rating: IP32
- Operating Temperature: -35°C to +45°C
- Dimensions: 8.27 x 5.94 x 2.34 inches
- Weight: 4.0 lbs
Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20) Documents:
Rich Solar 20 Amp MPPT Solar Charge Controller (RS-MPPT20) Specifications Sheet
