The Victron Energy Lithium SuperPack 12, 8V/20Ah (M5) Battery (BAT512020705) from Nomadic Supply Company® is compact 12.8V 20Ah Lithium SuperPack battery delivering advanced energy storage in a small, lightweight package. Perfect for portable applications, compact marine systems, and mobile power solutions where space and weight are critical factors. Features integrated battery management for hassle-free installation and safe operation.
Victron Energy Lithium SuperPack 12, 8V/20Ah (M5) Battery (BAT512020705) Features:
- LiFePO4 lithium chemistry for advanced energy density
- Integrated Battery Management System (BMS) and safety switch
- 92% round-trip energy efficiency
- Up to 2500 cycles at 80% depth of discharge
- Internal switch prevents over-discharge, overcharge, and excessive temperature
- Lightweight construction approximately 70% lighter than lead-acid batteries
- Can be connected in parallel for increased capacity
- Simple installation without additional components
- Bluetooth monitoring capability available with compatible systems
- M5 threaded insert terminals
Victron Energy Lithium SuperPack 12, 8V/20Ah (M5) Battery (BAT512020705) Specifications:
| Voltage | 12.8V nominal |
| Capacity | 20Ah (C20 rate) |
| Terminal Type | M5 insert |
| Dimensions (L x W x H) | 167 x 181 x 77 mm |
| Weight | 3.5 kg |
| Energy | 256Wh |
| Max Continuous Discharge | 30A |
| Peak Discharge (10 seconds) | 80A |
| Max Continuous Charge | 15A |
| Operating Temperature (discharge) | -20°C to +50°C |
| Operating Temperature (charge) | 0°C to +45°C |
| Cycle Life @ 80% DoD | 2500 cycles at 25°C |
| Warranty | 2 years |
Victron Energy Lithium SuperPack 12, 8V/20Ah (M5) Battery (BAT512020705) Documents:
LiFePO4 SuperPack Datasheet
Victron Energy Lithium SuperPack 12, 8V/20Ah (M5) Battery (BAT512020705) Owner’s Manual
Victron Energy Lithium SuperPack 12, 8V/20Ah (M5) Battery (BAT512020705) Datasheet
