The Victron Energy Lithium SuperPack 25, 6V/50Ah (M8) Battery (BAT524050705) from Nomadic Supply Company® is compact 25.6V 50Ah Lithium SuperPack battery delivering high-voltage energy storage in a lightweight package. Ideal for 24V systems requiring advanced lithium performance with integrated safety management for marine, solar, and mobile applications.
Victron Energy Lithium SuperPack 25, 6V/50Ah (M8) Battery (BAT524050705) Features:
- LiFePO4 lithium chemistry for superior energy density
- Integrated Battery Management System and safety switch
- 92% round-trip energy efficiency
- Up to 2500 cycles at 80% depth of discharge
- Automatic protection against over-discharge, overcharge, and excessive temperature
- Approximately 70% lighter than equivalent lead-acid batteries
- Can be connected in parallel for increased capacity
- Simple installation without additional components
- Compact design suitable for upright mounting only
- M8 threaded insert terminals
Victron Energy Lithium SuperPack 25, 6V/50Ah (M8) Battery (BAT524050705) Specifications:
| Voltage | 25.6V nominal |
| Capacity | 50Ah (C20 rate) |
| Terminal Type | M8 insert |
| Dimensions | Large format mobile |
| Weight | approximately 28 kg |
| Energy | 1280Wh |
| Max Continuous Discharge | 100A |
| Peak Discharge (10 seconds) | up to 200A |
| Max Continuous Charge | 50A |
| Operating Temperature (discharge) | -20°C to +50°C |
| Operating Temperature (charge) | 0°C to +45°C |
| Cycle Life @ 80% DoD | 2500 cycles at 25°C |
Victron Energy Lithium SuperPack 25, 6V/50Ah (M8) Battery (BAT524050705) Documents:
LiFePO4 SuperPack Datasheet
Victron Energy Lithium SuperPack 25, 6V/50Ah (M8) Battery (BAT524050705) Owner’s Manual
Victron Energy Lithium SuperPack 25, 6V/50Ah (M8) Battery (BAT524050705) Datasheet
