The Victron Energy MultiPlus 12/800/35-16 120V VE.Bus Inverter/Charger (PMP121800100) from Nomadic Supply Company® is an 800VA pure sine wave inverter/charger for 12VDC systems with 120VAC output. This compact unit is designed for backup power in RVs, boats, and mobile applications, supporting medical devices, security systems, and computer equipment with fast-acting UPS functionality.
Victron Energy MultiPlus 12/800/35-16 120V VE.Bus Inverter/Charger (PMP121800100) Features:
- Pure sine wave inverter output
- 800 VA continuous output at 25°C
- Built-in charger with up to 35 amp capacity
- Fast-acting transfer switch for UPS operation
- 16A transfer switch for load protection
- Fully programmable via Mk3 USB Interface
- VE.Bus connectivity for Victron ecosystem integration
- Compatible with Cerbo GX for remote monitoring via Victron VRM
Victron Energy MultiPlus 12/800/35-16 120V VE.Bus Inverter/Charger (PMP121800100) Specifications:
| DC Input Voltage Range | 9.5 – 17V |
| AC Output Voltage | 120V ±2% |
| AC Output Frequency | 60Hz ±0.1% |
| Continuous Output Power (25°C) | 800VA / 700W |
| Peak Power | 1600W |
| Maximum Efficiency | 92% |
| AC Input Voltage Range | 95 – 140V |
| Charge Current | 35A |
| Absorption Voltage | 14.4V |
| Float Voltage | 13.8V |
| Transfer Switch | 16A |
| Operating Temperature | -40 to +65°C |
| Weight | 6.4 kg |
| Dimensions (H×W×D) | 360 × 240 × 100 mm |
| Protection Category | IP 21 |
Victron Energy MultiPlus 12/800/35-16 120V VE.Bus Inverter/Charger (PMP121800100) Documents:
MultiPlus 500VA–2000VA Datasheet
Victron Energy MultiPlus 12/800/35-16 120V VE.Bus Inverter/Charger (PMP121800100) Owner’s Manual
