The Victron Energy Orion-Tr 24/48-8, 5A (400W) DC-DC Converter (ORI244841110) from Nomadic Supply Company® is an isolated step-up voltage converter for increasing 24-volt input to 48-volt output with 8.5-ampere continuous current and 400-watt power capacity. Providing galvanic isolation, adjustable output voltage, and remote control capability, it’s designed for isolated dual-voltage power distribution in marine and automotive systems.
Victron Energy Orion-Tr 24/48-8, 5A (400W) DC-DC Converter (ORI244841110) Features:
- Isolated step-up converter from 24V to 48V output
- Galvanic isolation prevents ground loops and reduces noise
- Input voltage range with wide compatibility window
- Output voltage adjustable approximately -15% to +25% from 48.2V default
- Continuous 8.5A output with 400W power rating
- Surge capability of 15A for 10 seconds
- Remote on-off control eliminates high-current switch requirement
- IP43 protection rating when installed with terminals down
- Screw terminals accommodate up to 6 AWG wire
- 5-year manufacturer warranty included
Victron Energy Orion-Tr 24/48-8, 5A (400W) DC-DC Converter (ORI244841110) Specifications:
| Input Voltage Range | 16-35V DC |
| Output Voltage Default | 48.2V |
| Output Voltage Adjustable | -15% to +25% from default |
| Continuous Output Current | 8.5A |
| Maximum Surge Current (10s) | 15A |
| Rated Power | 400W |
| Power at 25°C | 480W |
| Isolation | Galvanically isolated |
| Protection Rating | IP43 |
| Dimensions | 5.12″ × 2.76″ × 7.32″ |
Victron Energy Orion-Tr 24/48-8, 5A (400W) DC-DC Converter (ORI244841110) Documents:
Victron Energy Orion-Tr 24/48-8, 5A (400W) DC-DC Converter (ORI244841110) Owner’s Manual
