The Victron Energy Phoenix Inverter 24/800 230V VE.Direct SCHUKO (PIN241801200) from Nomadic Supply Company® is 24V to 230V pure sine wave inverter with 800VA capacity and Schuko receptacle outlet, designed for European installations. Features VE.Direct communication for remote monitoring and control. Suitable for powering a wide range of 230V equipment from 24V battery systems.
Victron Energy Phoenix Inverter 24/800 230V VE.Direct SCHUKO (PIN241801200) Features:
- Pure sine wave output at 230V, 800VA capacity
- VE.Direct communication port for monitoring
- Schuko receptacle outlet
- Maximum efficiency of 90%
- Eco mode with adjustable auto shutdown
- Compact design for mobile applications
- User-configurable settings
- Low battery voltage alarm
- Dynamic cut-off capability
- Suitable for marine and off-grid use
Victron Energy Phoenix Inverter 24/800 230V VE.Direct SCHUKO (PIN241801200) Includes:
- Inverter unit
Victron Energy Phoenix Inverter 24/800 230V VE.Direct SCHUKO (PIN241801200) Specifications:
| Continuous Power @ 25°C | 800VA / 640W |
| Continuous Power @ 40°C | 500W |
| Peak Power | 1500W |
| Input Voltage Range | 18.4 – 34V DC |
| Output Voltage | 230VAC ±2% |
| Output Frequency | 50Hz (fixed) |
| Maximum Efficiency | 90% |
| Zero-Load Power | 7.0W |
| Dimensions | 4.1″ H × 8.5″ W × 12.1″ D |
| Weight | 12 lbs |
| Protection Rating | IP21 |
| DC Cable Size | 4 AWG maximum |
Victron Energy Phoenix Inverter 24/800 230V VE.Direct SCHUKO (PIN241801200) Documents:
Phoenix Inverter VE.Direct 250–1600VA Datasheet
Victron Energy Phoenix Inverter 24/800 230V VE.Direct SCHUKO (PIN241801200) Owner’s Manual
