The Victron Energy Phoenix Inverter 48/3000 – 230V VE.Bus (PIN483020000) from Nomadic Supply Company® is 48V to 230V pure sine wave inverter with 3000VA capacity and VE.Bus communication port. Designed for professional and commercial applications requiring high-capacity power conversion. Features advanced parallel operation capability and European voltage output for international installations.
Victron Energy Phoenix Inverter 48/3000 230V VE.Bus (PIN483020000) Features:
- Pure sine wave output at 230V, 3000VA capacity
- VE.Bus communication port for advanced networking
- Supports parallel operation with up to 6 units
- High peak power output of 6000W
- High efficiency power conversion
- Temperature-compensated operation
- Fully configurable via VictronConnect software
- MK3-USB interface support
- Professional-duty construction
- Suitable for marine and commercial use
Victron Energy Phoenix Inverter 48/3000 230V VE.Bus (PIN483020000) Includes:
- Inverter unit
Victron Energy Phoenix Inverter 48/3000 230V VE.Bus (PIN483020000) Specifications:
| Continuous Power @ 25°C | 3000VA / 2400W |
| Continuous Power @ 40°C | 2000W |
| Peak Power | 6000W |
| Input Voltage Range | 36.8 – 62.0V DC |
| Output Voltage | 230VAC ±2% |
| Output Frequency | 50Hz (fixed) |
| Maximum Efficiency | 93% |
| Zero-Load Power | 20W |
| Protection Rating | IP21 |
| DC Cable Size | 1/0 AWG maximum |
| Communication | VE.Bus |
