The Victron Energy SmartSolar MPPT 250/60-MC4 Solar Charge Controller (SCC125060321) from Nomadic Supply Company® is a high-voltage charge controller with MC4 connectors for sophisticated multi-voltage systems. Supporting 12V to 48V batteries with 60A output and 250V solar input, this smart controller enables remote setup and monitoring. MC4 connectors ensure compatibility with modern high-voltage solar arrays.
Victron Energy SmartSolar MPPT 250/60-MC4 Solar Charge Controller (SCC125060321) Features:
- Built-in Bluetooth with VictronConnect integration
- Advanced MPPT algorithm for high-voltage systems
- MC4 solar connectors for standard compatibility
- 60A maximum charging current
- 250V solar input voltage
- Multi-voltage support: 12V, 24V, 36V, 48V
- Remote monitoring and configuration
- Fully programmable charging profiles
- Temperature-compensated charging
- PV short-circuit and reverse polarity protection
Victron Energy SmartSolar MPPT 250/60-MC4 Solar Charge Controller (SCC125060321) Specifications:
| Battery Voltage | 12V / 24V / 48V Auto Select |
| Rated Charge Current | 60A |
| Maximum PV Voltage | 250V |
| Maximum PV Short Circuit Current | 35A per MC4 connector |
| Nominal PV Power @ 12V | 860W |
| Nominal PV Power @ 24V | 1720W |
| Nominal PV Power @ 36V | 2580W |
| Nominal PV Power @ 48V | 3440W |
| Connector Type | MC4 |
| Maximum Efficiency | >99% |
Victron Energy SmartSolar MPPT 250/60-MC4 Solar Charge Controller (SCC125060321) Documents:
Victron Energy SmartSolar MPPT 250/60-MC4 Solar Charge Controller (SCC125060321) Owner’s Manual
