The Victron Energy SmartSolar MPPT RS 450/100-Tr Solar Charge Controller (SCC145110410) from Nomadic Supply Company® is an isolated, high-voltage charge controller designed for large 48V battery systems with 100A output. Supporting 450V solar input and featuring VE.Can networking, this advanced controller handles the largest off-grid and renewable energy installations. Isolated topology provides superior protection and flexibility.
Victron Energy SmartSolar MPPT RS 450/100-Tr Solar Charge Controller (SCC145110410) Features:
- Isolated MPPT topology for advanced protection
- 450V maximum solar input voltage
- 100A charging output for 48V systems
- VE.Can connectivity for networking
- Screw-terminal connections for industrial use
- Programmable relay for automated control
- Remote temperature and voltage sensing
- Daisy-chain up to 25 units
- BMS integration capability
- Active cooling system
Victron Energy SmartSolar MPPT RS 450/100-Tr Solar Charge Controller (SCC145110410) Specifications:
| Input Voltage Range | 65V – 450V DC |
| Output Voltage | 48V DC |
| Rated Charge Current | 100A |
| Maximum Power Output | 5.76kW |
| Efficiency | >98% |
| Cooling | Active fan cooling |
| Communication | VE.Can + Bluetooth |
| Connector Type | Screw Terminal |
| Operating Temperature | -30°C to 60°C |
| Synchronizable Units | Up to 25 units |
Victron Energy SmartSolar MPPT RS 450/100-Tr Solar Charge Controller (SCC145110410) Documents:
SmartSolar MPPT RS Datasheet
SmartSolar MPPT RS Manual
Victron Energy SmartSolar MPPT RS 450/100-Tr Solar Charge Controller (SCC145110410) Owner’s Manual
